DPX
DIN 24550 filter elements for pressure applications
Materials
End ring: Steel
End cap: Steel
Seals: NBR Nitrile (FKM Fluoroelastomer on request)
PRESSURE
Collapse, differential for the filter element:
standard series 2,1 MPa (21 bar)
H+ series for high pressure applications 21 MPa (210 bar)
WORKING TEMPERATURE
From -25° to +110° C with NBR Nitrile seals
(From -20° to + 140° C with FKM Fluoroelastomer seals)
DRX
MATERIALS
End rings: Zinc plated steel
Seals: NBR Nitrile (FKM Fluoroelastomer on request)
PRESSURE
Collapse, differential for the filter element:
1 MPa (10 bar)
WORKING TEMPERATURE
From -25° to +110° C with NBR Nitrile seals
(From -20° to + 140° C with FKM Fluoroelastomer seals)
FLA
Inline high pressure last chance filter
Materials
Housing: Aluminum
Seals: NBR Nitrile
Pressure
Max. working: 21 MPa (210 bar) Collapse, differential for the filter element: 8 MPa (80 bar)Flow rate
Qmax 35 l/minWorking temperature
From -25° to +110° CCompability (ISO 2943)
Full with fluids: HH-HL-HM-HV-HTG (according to ISO 6743/4) For fluids different than the above mentioned, please contact our Customer Service
CAL
In-line suction element
Materials
Housing: Zinc plated steel
Working temperature
From -25° to +110° C
Flow rate
Qmax 100 l/min
ESA – ESB
Suction strainer
Materials
Connector: Polyamide
(Aluminum for ESA & ESB 51 - 52)
End cap: Polyamide
(Zinc plated steel for ESA & ESB 51 - 52)
Bypass valve: (ESA) Polyamide
Magnetic core: (ESB) Syntherized magnetic material
Pressure
Collapse, differential: 100 kPa (1 bar)
Bypass valve
Setting: 30 kPa (0,3 bar) ± 10%
Working temperature
From -25° to +110° C
Flow rate
Qmax 600 l/min
FAM
Suction strainer
Materials
Connector: Aluminum
Internal core: Zinc plated steel
End cap: Zinc plated steel
Pressure
Collapse, differential for filter element: 100 kPa (1 bar)
Working temperature
From -25° to +110° C
Flow rate
Qmax 600 l/min
FMA
Multipurpose filter
Materials
Head: Aluminum alloy
Bowl: Cold formed steel
Seals: NBR Nitrile (FKM Fluoroelastomer on request)
Indicator housing: Brass
Pressure
Max working: 0,7 MPa (7 bar)
Collapse, differential for the filter element (ISO 2941): 300 kPa (3 bar)
Working temperature
From -25° to +110° C
Flow rate
Qmax 600 l/min
FSC
Suction filter
Materials
FSC31 & FSC41
Cover & head: Aluminum alloy
Bowl: Polyamide
FSC71 & FSC81
Cover & housing: Aluminum
FSC51 & FSC61
Housing: Steel |
Cover: Aluminum
Shut-off valve: Polyamide
Seals: NBR Nitrile
(FKM fluoroelastomer on request )
Indicator housing: Brass
Pressure
Collapse, differential for the filter element: 100 kPa (1 bar)
Working temperature
From -25° to +110° C
Flow rate
Qmax 500 l/min
FSE
Suction spin-on filter
Materials
Head: Aluminum alloy
Spin-on cartridge: Steel
Bypass valve: Polyamide
Seals: NBR Nitrile (FKM fluoroelastomer on request )
Indicator housing: Brass
Pressure
Collapse, differential for filter element: 400 kPa (4 bar)Bypass valve
Setting: 30 kPa (0,30 bar) ± 10%
Working temperature
From -25° to +110° C
Flow rate
Qmax 75 l/min
FSG
Tank side wall suction filter
Materials
Lid: Polyamide
Housing: Aluminum alloy
Seals: NBR Nitrile
Pressure
Collapse, differential for filter element: 1 MPa (10 bar)
Working temperature
From -25° to +110° C
Flow rate
Qmax 70 l/min
FPA
Medium pressure inline filter
Materials
Housing: Anodized aluminium alloy
Bypass valve: Brass
Seals: NBR Nitrile (FKM Fluoroelastomer - on request)
Indicator housing: Brass
Pressure
Max working: 11 MPa (110 bar)
Collapse, differential for the filter element: 8 MPa (80 bar)
Bypass valve
Setting: 600 kPa (6 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 60 l/min
MSZ
Suction strainer
Materials
Connector: Polyamide
Internal core: Zinc plated steel
End cap: Zinc plated steel
Pressure
Collapse, differential: 100 kPa (1 bar)Working temperature
From -25° to +90° C
Flow rate
Qmax 600 l/min
FPB
High pressure inline filter
Materials
Head: Cast iron
Bowl: Steel
Bypass valve: Steel
Seals: NBR Nitrile (FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max working: 42 MPa (420 bar)
Collapse, differential for the filter element (ISO 2941):
series standard 2 MPa (20 bar)
series H+ 21 MPa (210 bar)
Bypass valve
Setting: 600 kPa (6 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 450 l/min
FPC
High pressure inline filter
Materials
Head: Cast iron
Bowl: Steel
Bypass valve: Steel
Seals: NBR Nitrile
(FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max. working: 35 MPa (350 bar) Collapse, differential for the filter element standard series 2 MPa (20 bar)
H+ series 21 MPa (210 bar)
Bypass valve
Setting:
350 kPa (3,5 bar) ± 10%
600 kPa (6 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 150 l/min
FPE
Inline spin-on filter
Materials
Head: Aluminium alloy
Spin-on cartridge: Steel
Bypass valve: Polyammide
Seals: NBR Nitrile
(FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max working: 1,2 MPa (12 bar)
Collapse, differential for the filter element: 400 kPa (4 bar)
Bypass valve
Setting: 170 kPa (1,7 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 300 l/min
FPG
Medium pressure filter
Materials
Head: Aluminium alloy
Bowl: Steel
Bypass valve: Steel
Seals: NBR Nitrile (FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max working: 5 MPa (50 bar)
Collapse, differential for the filter element (ISO 2941): 1 MPa (10 bar)
Bypass valve
Setting: 350 kPa (3,5 bar) ±10%
Working temperature
From -25° to +110° C
Portata
Qmax 400 l/min
FPH
3-way inline filter
Materials
Head: Aluminium alloy
Bowl: Steel
Bypass valve: Polyammide
Seals: NBR Nitrile
Indicator housing: Brass
Pressure
Max working: 2 MPa (20 bar)
Collapse, differential for the filter element: 300 kPa (3 bar)
Bypass valve
Setting: 170 kPa (1,7 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 400 l/min
FPL
Pressure filter manifold side mounting
Materials
Head: Cast iron
Bowl: Steel
Bypass valve: Steel
Seals: NBR Nitrile (FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max working: 31,5 MPa (315 bar)
Collapse, differential for the filter element
standard series: 2 MPa (20 bar)
H+ series: 21 MPa (210 bar)
Bypass valve
Setting: 600 kPa (6 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 400 l/min
FPM
Medium pressure inline filter
Materials
Housing: Anodized aluminium alloy
Bypass valve: Steel
Seals: NBR Nitrile (FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max working: 21 MPa (210 bar)
Collapse, differential for the filter element: 2,1 MPa (21 bar)
Bypass valve
Setting: 600 kPa (6 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 120 l/min
FPO
High pressure spin-on filter with FORTIMAX element
Materials
Head: Aluminium alloy
Spin-on housing: Steel
Bypass valve: Polyammide
Seals: NBR Nitrile
(FKM - on request fluoroelastomer)
Indicator housing: Brass
Pressure
Max working: 3,5 MPa (35 bar) for FPO1+ and 2,5 MPa (25 bar) for FPO2+/p>
Collapse, differential for the filter element: 1 MPa (10 bar)
BYPASS VALVE
Setting:
170 kPa (1,7 bar) ± 10%
350 kPa (3,5 bar) ± 10%
WORKING TEMPERATURE
From -25° to +110° C
Flowrate
Qmax 250 l/min
FRA
Tank Top Return Line Filter
Materials
Head and cover : Aluminum alloy
Bowl :
Polyamide for FRA21-31-32-33-41
Zinc plated steel for FRA11-42-51-52- 53-5D
Bypass valve: Polyamide
Seals: NBR Nitrile (FKM Fluoroelastomer on request)
Indicator housing: Brass
Pressure
Max. working: 300 kPa (3 bar)
Collapse, differential for the filter element (ISO 2941): 300 kPa (3 bar)
Bypass valve
Setting: 170 kPa (1,7 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 700 l/min
FRB
Tank top return line filter, inbuilt breather
Materials
Head : Aluminum alloy
Cover and Bowl: Polyamide
Bypass valve: Polyamide
Seals: NBR Nitrile
Indicator housing: Brass
Pressure
Max. working: 700 kPa (7 bar)
Collapse, differential for the filter element (ISO 2941): 300 kPa (3 bar)
Bypass valve
Setting: 170 kPa (1,7 bar) ± 10%
250 kPa (2,5 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 140 l/min
FRC
Tank top return spin-on filter
Materials
Head : Aluminum alloy
Spin-on cartridge: Steel
Bypass valve: Polyamide
Seals: NBR Nitrile
Indicator housing: Brass
Pressure
Max. working: 700 kPa (7 bar)
Collapse, differential for the filter element (ISO 2941): 300 kPa (3 bar)
Bypass valve
Setting: 170 kPa (1,7 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 200 l/min
FRD
Tank top or external mounting return line filter
Materials
Cover & housing: Anodized aluminum alloy
For 61&62 only, Cover: Anodized aluminum alloy
Housing: Steel
Bypass valve: Steel
Seals: NBR Nitrile (FKM Fluoroelastomer on request )
Indicator housing: Brass
Pressure
Max. working: 2 MPa (20 bar)
Collapse, differential for the filter element (ISO 2941): 1 MPa (10 bar)
Bypass valve
Setting: 300 kPa (3 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 1500 l/min
FRF
In-out tank top return line filter
Materials
Head and cover: Aluminum alloy
Diffusor: Zinc plated steel
Element support:
Polyamide (aluminum alloy for FRF3+ and FRF4+)
Magnetic core: Syntherized magnetic material
Seals: NBR Nitrile (FKM Fluoroelastomer on request)
Indicator housing: Brass
Pressure
Max. working: 1 MPa (10 bar)
Collapse, differential for the filter element (ISO 2941): 1 MPa (10 bar)
Bypass valve
Setting: 150 kPa (1,5 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 2200 l/min
FRG
Tank insert return line filter, inside to outside filtration
Materials
Diffusor: Zinc plated steel
Element support: Polyamide (aluminum alloy for FRG3+ & FRG4+)
Magnetic core: Syntherized magnetic material
Seals: NBR Nitrile
FKM Fluoroelastomer on request
Pressure
Collapse, differential for the filter element (ISO 2941): 1 MPa (10 bar)
Bypass valve
Setting: 150 kPa (1,5 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 2400 l/min
FRH
Tank top return filter
Materials
Head and cover: Aluminum alloy
Bowl: Polyamide
Bypass valve: PolyaqMAmide
Seals: NBR Nitrile
FKM Fluoroelastomer on request
Indicator housing: Brass
Pressure
Max working: 300 kPa (3 bar)
Collapse, differential for the filter element (ISO 2941): 300 kPa (3 bar)
Bypass valve
Setting: 170 kPa (1,7 bar) ± 10%
Working temperature
From -25° to +110° C
Flowrate
Qmax 200 l/min
FRI
Tank top or external mounting return line filter
Materials
Head : Aluminum alloy
Cover and Bowl: Aluminum alloy
Bypass valve: Polyamide
Seals: NBR Nitrile
Indicator housing: Brass
Pressure
Max. working: 1000 kPa (10 bar)
Collapse, differential for the filter element (ISO 2941):
300 kPa (3 bar)
Bypass value
Setting: 170 kPa (1,7 bar) ± 10%
Flow rate
Qmax 250 l/min
Working temperature
From -25° to +90° C
GRF
Ecofriendly in-out tank top return filter
Materials
Head and cover: Aluminum alloy
Diffusor: Zinc plated steel
Element support: Aluminum alloy
Magnetic core: Syntherized magnetic
material Seals: NBR Nitrile (FKM Fluoroelastomer on request)
Indicator housing: Brass
Pressure
Max. working: 1 MPa (10 bar)
Collapse, differential for the filter element (ISO 2941): 1 MPa (10 bar)
BYPASS VALVE
Setting: 170 kPa (1,7 bar) ± 10%
Flow rate
Qmax 1200 l/min
Working temperature
From -25° to +110° C
Compability (ISO 2943)
Full with fluids: HH-HL-HM-HV-HTG
(according to ISO 6743/4)
For fluids different than the above mentioned, please contact
our Customer Service.
XTT
High pressure inline filter
Materials
Head: Cast iron Bowl: Steel Bypass valve: Steel Seals: NBR Nitrile (FKM Fluoroelastomer on request) Indicator housing: BrassPRESSURE
Max. working: 31,5 MPa (315 bar) Collapse, differential for the filter element series standard 2,1 MPa (21 bar)BYPASS VALVE
Setting: 350 kPa (3,5 bar) ± 10% 600 kPa (6 bar) ± 10%FLOW RATE
Qmax 95 l/minWORKING TEMPERATURE
From -25° to +110° C
XTU
High pressure inline filter
Materials
Head: Cast iron
Bowl: Steel
Bypass valve: Steel
Seals: NBR Nitrile
Indicator housing: Brass
PRESSURE
Max. working: 31,5 MPa (315 bar)
Collapse, differential for the filter element
series standard 2,1 MPa (21 bar)
BYPASS VALVE
Setting: 350 kPa (3,5 bar) ± 10% 600 kPa (6 bar) ± 10%FLOW RATE
Qmax 95 l/minWORKING TEMPERATURE
From -25° to +110° C
HYDRO-DRY
Water removal elements
FEATURES
The hydro-dry filter elements remove up to 80% of the free water present in the oil.
The hydro-dry elements use the FormulaUFI.H2O filter media, working by absorption and ensuring a high water retention capacity.
To get the maximum water removal efficiency the hydro-dry elements must be used at constant flow rate and low and constant pressure, i.e. the ideal use is in off-line filters or in filtration units.
The hydro-dry elements remove also the solid contamination (ß21(c) > 1.000), but we recommend to remove the main part of solid contamination using a dedicated return line filter.
The hydro-dry elements are available in standard dimensions, to fit standard filter housings.
A clogging indicator set at 130 kPa (1,3 bar) on the filter housing is recommended for proper replacement of the clogged element.
UOW022
Portable filling and filtration unit
FEATURES
Inlet: flexible hose Steelflex 16HNA, 2,5 m long with rigid end DE16 0,4 m long
Outlet: flexible hose Steelflexx 13HNA, 2,5 m long with rigid end DE12 0,4 m long
“Y” type filter for pump protection
Gear pump 22 l/min, 2800 rpm
Electric motor single phase 230V - 0,25 kW – 2 poles - B3/B5
Double handle for easy and safe transportation
Total weight 16,5 kg
HOW IT WORKS
The mobile filtration unit is used for cleaning the fluid off line, for the transfer, filling and topping up of the oil tank and for any roll-off operation. The oil returning to the tank-reservoir from the return line is filtered by the UOW unit, reducing drastically the “clean-up time.” The filter can be fitted with a visual clogging indicator, also of differential type
FLOWRATE
Qmax 22 l/min
UOW040
Portable filling and filtration unit with green element
FEATURES
Inlet and Outlet flexible hose, 2 m long with rigid end 0,5 m long
“Y” type filter for pump protection
Gear pump 40 l/min with inbuilt 1 MPa (10 bar) relief valve
Electric motor: three phase 380V - 0,75 kW 1450 rpm - IP54
Double handle for proper and easy transportation
WEIGHT
50 Kg
HOW IT WORKS
The mobile filtration unit is used for cleaning the fluid off line, for the transfer, filling and topping up of the oil tank and for any roll-off operation.
The UOW mobile off-line filtration unit filters hydraulic fluid at low-pressure with the aid of a self-contained pump, motor and filter.
The construction design is compact and user-friendly, and guarantees high filtration performances and long life filter element.
FLOWRATE
Qmax 40 l/min
FTA – FTB
Hydrostatic transmission filter
Materials
Head: Aluminum alloy
Cover: Polyamide FTA-FTB2
Aluminum alloy FTA-FTB3
Bowl: Steel
Seals: NBR Nitrile
Indicator housing: Brass
Pressure
Max working: 1 MPa (10 bar)
Collapse, differential for the filter element (ISO 2941): 1 MPa (10 bar)
Bypass valve
Setting: 250 kPa (2,5 bar) ± 10%
Working temperature
From -25° to + 110° C
FLOWRATE
Qmax 240 l/min
CBA
Air breather, hand mounting
Materials
Housing, flange and basket:
Zinc plated steel
Cap: Chrome plated
Filter element
(not replaceable, filtration degree in air):
Impregnated cellulose 3µm
Polyurethane foam 10µm
FLOW RATE
Qmax 750 l/min
Working temperature
From -25°C to +110°C
CBB
Air breather with threaded connection
Materials
Housing and threaded connection:
Zinc plated steel
FLOW RATE
Qmax 500 l/min
Spare filter element
Replaceable filter element:
Impregnated cellulose 10 µm
(filtration degree in air)
Working temperature
From -25°C to +110°C
CBC
Air breather filter, extension tube available on request
Materials
Housing and basket: Plastic
Basket: Plastic
Seal: Nitrile NBR
FLOW RATE
Qmax 1800 l/min
Spare filter element
Impregnated cellulose 3 µm
(Filtration degree in air)
Working temperature
From -25°C to +110°C
CBD
Air breather, thread mounted
Materials
Housing: Black painted steel
Flow rate
Qmax 1500 l/min
Spare filter element
Filtration degree in air
VD - Velvet mesh 10 µm
FD - Fibreglass 2,5 µm (on request only)
CD - Impregnated cellulose 10 µm (on request only)
Working temperature
From -25°C to +110°C
CBE
Air breather, flange mounting
Materials
Housing: Black painted steel
Flow rate
Qmax 20000 l/min
Spare filter element
Filtration degree in air
VD - Velvet mesh 10 µm
FD - Fibreglass 2,5 µm (on request only)
CD - Impregnated cellulose 10 µm (on request only)
Working temperature
From -25°C to +110°C
CBF
Air breather, clamp mounting
Materials
Housing: Black painted steel
Clamp: Stainless steel
FLOW RATE
Qmax 4000 l/min
Spare filter element
Filtration degree in air
VD - Velvet mesh 10 µm
FD - Fibreglass 2,5 µm (on request only)
CD - Impregnated cellulose 10 µm (on request only)
Working temperature
From -25°C to +110°C
CBS
Air breather with spin-on element
Materials
Connector: Steel
(Zinc plated for the flanged version)
Spin-on can: Steel
FLOW RATE
Qmax 2800 l/min
Spare filter element
CC = Impregnated Cellulose
FD = Fibreglass
Filtration degree in air 3 µm
Working temperature
From -25°C to +110°C
CSE
Air breather with spin-on element
Materials
Connector: Zinc plated steel
Basket: Zinc plated steel
Spin-on can: Steel
FLOW RATE
Qmax 2800 l/min
SPARE FILTER ELEMENT
CC = Impregnated Cellulose
FD = Fibreglass
Filtration degree in air 3 µm
Working temperature
From -25°C to +110°C
AIR SENTRY
Air dryer filter breather
Materials
D-10+ are manufactured from rugged ABS plastic and impact-modified Plexiglas.
R-10+ have a rugged steel reinforced base for heavy duty applications
Nominal air flow rate
1.000 l/min
Technical data
Solid contaminant filtration: 2 µm
Silica gel adsorption: up to 40% of its weight in water
Working temperature
From -30°C to 100°C
CFA
Filling breathers
CFA filling plugs include an inbuilt air breather and a protection basket against ingression of coarse parts (removable for CFA23). The connection to the tank is flanged with standard dimensions, with additional tank connection options for CFA23 (welding flange or plug extension).
Filter element
Filter element (not replaceable):
Impregnated cellulose 3µm
Polyurathan foam 10µm
For sizes CFA21 & CFA22 the plug has a safety chain.
CLA
Materials
Transparent part: Trogamid T
Anti-shock protection: Painted steel
Fixing bolts: zinc plated steel
Seals: NBR Nitrile (FKM Fluoroelastomer on request)
Double scale thermometer (Celsius and Farenheit) option available.
Tightening torque for the fixing bolts 10 Nm
Visual level indicators
Pressure
Max pressure allowed 100 kPa (1 bar)
Working temperature
From -20°C to +90°C
CLB
Materials
Tank connection: Anodized aluminium
Rod: Stainless steel
Float: Polyammide
Float switches
Electrical level indicators, an electrical signal is activated when the minimum (or maximum) oil level is reached. The REED switch has SPDT contacts.
N.B. the float switch must be mounted at min 50 mm from ferrous walls. Max oil viscosity 150 cSt.
Working temperature
From -10°C to +90°C
FAB
Materials
Housing: black painted steel
Internal parts: steel
Filter element: zinc painted steel (stainless steel on request)
Prefilter transparent housing and buffle: plastic material
Seals: NBR Nitrile
Description
Oil bath air filter and cyclone prefilter
Working temperature
Max working temperature: 95°C
Flow rate: 3.000 to 12.000 l/min
Clogging indicators for pressure filters
